Cordless chainsaw KSC 60 EB-Basic KAPEX

• Precise: Double-bearing double-column guide for exact, smooth sawblade guidance
• Versatile: Miter angles up to 60 degrees on both sides and tilt angles up to 46 or 47 degrees on both sides
• Durable: Combination of brushless EC-TEC motor and dual battery system delivers maximum power
• Mobile: Low weight, compact design, comfortable carrying handles
• Working according to the material: With sawblades for every material and speed preselection for material-appropriate speed
• Working with little dust: Dust bag for low-dust work even without a mobile dust extractor
• Simple: Angle bevel for measuring inside and outside angles
• Precise: LED spotlight for cutting line display and optimal view of the scribe mark
• Flexible: Table extension for the secure support of longer workpieces
• Clever: The Additional feet raise the work table of the KSC 60 to exactly the height of the Systainer SYS 3 M 112 or SYSTAINER SYS 1.
• Angle-correct: Precise, clearly visible angle scale. Either with preset angles via locking points or completely individually with easy-to-use clamping.
• Very straightforward: Changing the saw blade is done in a flash with the spindle stop.

The new cordless KAPEX KSC 60 delivers unbeatably precise miter cuts – and does so in an enormous variety of applications thanks to miter angles of up to 60 degrees on both sides and tilt angles of up to 46 or 47 degrees on both sides. The double-bearing double-column guide ensures precise, smooth saw blade guidance: This ensures perfect every saw cut, without any wobbling or jerking. The brushless EC-TEC motor in combination with the dual battery system ensures almost endless endurance – this is enough for the entire workday in all typical applications. And last but not least, clever details such as speed preselection, saw blades for every application, angle bevel, ergonomic base frame, and dust collection bag ensure ergonomic, healthy, and highly professional work.

Main Applications

• Ideal for mobile use during assembly
• Cutting boards and panels up to 305 x 60 mm
• Cutting strips, profiles, and squared timber up to 60 mm thick
• Precisely fitting baseboards and cover boards without any calculations - in combination with the angle bevel

Technical Data

• Battery voltage: 2 x 18 V
• No-load speed: 1300 - 1800/3500 rpm
• Saw blade diameter: 216.00 mm
• Cutting depth 90°/90°: 305 x 60 mm
• Cutting depth 45°/90°: 215 x 60 mm
• Cutting depth 45°/45° (left): 215 x 40 mm
• Cutting depth 45°/45° (right): 215 x 20 mm
• Incline angle: 47/46 °
• Miter angle: 60/60 °
• Cutting depth 60°/90°: 150 x 60 mm
• Dust extraction connection Ø: 27/36 mm

Dimensions(W x D x H): 639 x 459 x 442 mm

Weight: 17.3 kg
