4-wheel electric vehicle Assisi 2.0, 6 km/h, Safety Plus: 36V/15.6Ah Li-Ion, with luggage bag/basket, indicators, foldable, blue

• 4-wheel electric vehicle Assisi 2.0 – practically foldable with a larger, comfortable footboard
• 2x 250-watt direct drive on the rear axle
• Maintenance-free ride comfort – up to 6 km/h and a range of up to 35 km* (our Eco Standard)
• Removable front luggage bag and spacious rear luggage basket
• For use on sidewalks and bike paths, as well as in pedestrian zones
• Sturdy steel frame – single brake – pneumatic tires
• Powerful 36V/15.6Ah lithium-ion battery
• High-quality plastic paneling with additional front paneling
• Permissible total weight up to 120 kg

The 4-wheel electric vehicle "Assisi 2.0" will not only make your everyday life easier, it is also the ideal Travel companion: it can be easily disassembled into 4 parts and fits in almost any trunk! With its luggage bag and spacious basket, you can do your shopping independently, making you mobile independently.

"With the 4-wheel electric vehicle "Assisi 2.0," you stay mobile – whether at home or traveling, you're now even more innovative on the go: with an extra-large comfortable footboard and additional front panel. Thanks to a practical folding mechanism, it can be disassembled and easily stowed away. Its luggage bag and spacious basket offer plenty of storage space. This everyday companion can be ridden without a helmet or a driver's license and is covered by your half-compulsory insurance; you don't need an insurance license plate."

Technical Specifications

• Motor/Drive: Rear wheel hub motors 2x250 watts (maintenance-free)
• Motor control: Integrated into the chassis
• Motor power (W): 500
• Battery: Lithium-ion (maintenance-free)
• Voltage: 36V/15.6Ah
• Battery capacity (Wh): 561.6
• Installation type: Battery installed behind the footboard - replaceable
• Battery charging time: approx. 6 to 8 hours
• Max. range* (our Eco standard) up to (km): 35
• Top speed (depending on weather, ground conditions, environment and weight) up to (km/h): 6
• Max. Gradeability approx. (%): 12
• Frame/Covering: Sturdy steel frame, plastic cover with additional front cover
• Gearbox: Automatic - continuously adjustable via throttle twist grip, with reverse gear
• Brakes: Rear disc brake, additional parking brake
• Tires: Front: Pneumatic tires with valve, 10 inch 10x2.125, Ø 25 cm / Rear: Solid rubber tires 8 inch 200x50, Ø 20 cm (ground clearance approx. 10 cm)
• Steering: Handlebar grip as on a moped/motorcycle (handlebar height adjustable from 72-95 cm, or 54-76 cm measured from the footboard)
• Control unit: Key switch and continuously variable twist grip operation, LED display with speedometer, charge level indicator and Driving light indicator light
• Front lighting: LED headlights with daytime running lights, as well as additional indicators
• Rear lighting: LED taillight with brake light function, as well as additional indicators
• Seat/bench: Adjustable and removable comfort seat with textile leather cover (approx. L 40 x W 38 cm) and fold-up armrests, seat backrest foldable (approx. L 40 x W 22 cm), seat height approx. 60 cm
• Suspension: Double rear suspension
• Splash guards: front and rear
• Footboard: Non-slip and extra-large (approx. L 35 x W 37 cm), entry height approx. 19 cm

Dimensions: approx. L 137 x W 60 x H 95 cm (folded approx. L 37 x W 60 x H 72 cm)

Battery weight: approx. (kg): 3

Weight including battery: approx. (kg): 38.5

Permissible total weight: approx. (kg): 120

Scope of delivery

• Vehicle
• Battery
• Charger (length of charging cable approx. 150 cm)
• Attachments such as luggage bag at the front and luggage basket at the rear (50 x 27 x 27 cm)
• Operating instructions

Legal information for Germany and notes:

• Driver's license: Minimum age 15 years (§ 10 FeV): No driving license required. Considered a wheelchair lift (Section 4, Paragraph 2): maximum width of 110 cm, maximum unladen weight of 300 kg, maximum total weight of 500 kg, electric drive, max. one seat. With a special permit, this vehicle may be driven even without a minimum age requirement.
• Insurance/License Plate: Vehicles up to 6 km/h are exempt from insurance, but should be included in your private liability insurance. Informing your private liability insurer is usually sufficient for this. No license plate is required.
• Helmet Requirement: There is no helmet requirement for drivers of motorcycles that do not reach a design-related speed higher than 20 km/h (6th Exception Regulation to the StVZO dated March 24, 1994).
• Approval: Use on sidewalks and cycle paths and in pedestrian zones at walking pace (max. 6 km/h). No registration required, no TÜV required.
• Tax: Tax-free
• Warranty/Guarantee: 6-month warranty on the battery and 6-month warranty on wearing parts
• Replacement guarantee: 5 years on the battery, 5 years on spare parts
• Assembly instructions: The electric vehicle is delivered 90% pre-assembled by parcel service. Unfold, install the seat, charge the battery, and perform a function and safety check.

*Important information on range

The vehicle's range in kilometers is influenced by several factors: the driver's defensive or offensive driving style (constantly at full throttle or not), payload: weight of the driver and luggage, route topography: flat terrain or mountainous routes, road surface characteristics: gravel roads, cobblestones, asphalt, etc., low tire pressure, weather influences such as headwinds, wet road surfaces, etc., climate, temperature, and humidity. Under optimal conditions (straight, paved road, no headwind, dry weather, a payload of approximately 70 kg, and defensive driving), the vehicle achieves the stated range. The range can be significantly reduced under adverse conditions.
